| Load Type | RW (DM/DB) | RW (D) | RWH (DM/DB) | RWH (D) |
|---|---|---|---|---|
| Rated Load (Resistive) |
12A 120VAC(UL) 10A 120VAC 10A 24VDC |
12A 120VAC(UL) 10A 120VAC 10A 24VDC |
12A 250VAC(UL) 10A 277VAC(TUV) 15A 120VAC 15A 24VDC |
12A 250VAC(UL) 10A 277VAC(TUV) 15A 120VAC 15A 24VDC |
| Contact capacity | - | - |
TV-5 120VAC (N/O) Tungsten (1800W) Tungsten (1800W) |
TV-5 120VAC (N/O) Tungsten (1800W) Tungsten (1800W) |
| Rated Carrying Current | 12A | 12A | 15A | 15A |
| Max. Allowable Voltage |
AC 240V DC 110V |
AC 240V DC 110V |
AC 240V DC 110V |
AC 240V DC 110V |
| Max. Allowable Current | 12A | 12A | 15A | 15A |
| Max. Allowable Power Force |
1440VA 240W |
1440VA 240W |
3000VA 360W |
3000VA 360W |
| Contact Material | Ag Alloy | Ag Alloy | Ag Alloy | Ag Alloy |
| Contact Form | SPST | SPDT | SPST | SPDT |
Main Feature
- High switching current up to 15A in small size.
- Sugar-Cube relay suitable for various applications.
- UL, C-UL & TÜV safety standard approved
- UL Class F insulation available
- Highly adapt to harsh conditions with high temperature and vibration.
- Halogen Free series available.
- Comply with RoHS and REACH regulations
- In accordance with IEC 60335-1 Glow Wire requirements for home appliances.
Application
Domestic Appliances, Office Machines, Audio Equipment, Coffeepot, Control Units, etc.
